Plastic Coated Copper Pipes & Tubes

The Plastic Coating is a LDPE with a World Wide UV stabiliser.
Resistance to some common chemicals below:

Very good chemical resistance Good Chemical Resistance Medium Chemical Resistance Poor Chemical Resistance
Acetatic acid Amonium hydroxide 30%
Calcium hydroxide 30% Diethylene glycol Ethylene glycol
Ethanol 100% Glycerin Glycol
Hydrogen peroxide 30% Mercury Methanol
Potassium hydroxide 30%
Sodium hydroxide 30%
Acetone Formaldehyde 10-40% Gas oil
Caproic acid Iodine Isobutanol Isopropanol Mineral oil Motor oil Natural gas Gasoline Phenol
Tranformer oil Vaseline
Dibutylether Ethylene acetate 100%
Furfurol 100% Heptane Paraffin
Diethylether Ethylenechloride Hydrogen peroxide 90% Methylene chloride
LDPE coating would have no chemical resistance from Acetylene dichloride

The Physical properties are as follows:

Melting point:114°C
Vicat Softening Point:93°C (Maximum Operating Temperature)
Brittleness Point:< -75°C
Hardness:55 Shore D
Tensile Break:13.40 MPa
Flexural Strength:8.10 MPa
Elongation at Break500%
Volume Resistivity>1015 Ohm-cm³
Surface Resistivity:>1015 Ohm-cm²

This range is ideal for use within walls, outside, underground and in aggressive atmospheres. The covering creates a thermal barrier reducing heat loss underground and condensation from exposure in extreme weather conditions.

Tubes can withstand temperatures from -40 to +114°C and can be bent (except 35-54mm) and jointed as per standard plain EN1057 tubes using EN1254 fittings. To expose bare copper, plastic coating needs to be cut and pulled back away from the joint and flame (if brazing). Once joint has been made coating needs returning back to original position and both joint and cut need to be protected using an impervious plastic tape. See Plastic Coated Copper Tube Installation Guide for specific details.

White PE Coated Copper Tubes

to BS EN 13349 / BS EN 1057 R250/R290

Product CodeO.D. (mm)Length (m)Wall (mm)PE Thickness
TXPEW015153, 5.8 & 60.71.0
TXPEW022223, 5.8 & 60.91.0
TXPEW028283, 5.8 & 60.91.0
TXPEW035353, 5.8 & 61.21.5
TXPEW042423, 5.8 & 61.21.5
TXPEW054543, 5.8 & 61.21.5
TXPEW067673, 5.8 & 61.21.5
TXPEW076763, 5.8 & 61.51.5
TXPEW1081083, 5.8 & 61.51.5

PVC Covered Coils

to BS EN 1057 R220

Product CodeO.D. (mm)Length (m)Wall (mm)PVC Thickness
TWPVCBLK0088 PVC Black250.81.0
TWPVCW0088 PVC White250.61.0
TWPVCW01010 PVC White25 & 500.71.0
TWPVCY01515 PVC Yellow/Blue251.01.5
TWPVCY02222 PVC Yellow/Blue251.21.5
TWPVCY02828 PVC Yellow201.21.5

PVC Covered Tube

to BS EN 1057 R250

Product CodeO.D. (mm)Length (m)Wall(mm)PVC Thickness
TXPVCY01515 PVC Yellow3 & 60.71.0
TXPVCY022                            22 PVC Yellow3 & 6   0.91.0
TXPVCY02828 PVC Yellow3 & 60.91.0

Green PE Coated Copper Tubes

to BS EN 13349 / BS EN 1057 R250/R290

Product CodeO.D. (mm)Length (m)Wall (mm)PE Thickness
TYPEG015155.8 & 60.7 or 1.01.0
TYPEG022225.8 & 60.9 or 1.21.0
TYPEG028285.8 & 60.9 or 1.21.0
TYPEG035355.8 & 61.0 or 1.51.5
TYPEG042425.8 & 61.0 or 1.51.5
TYPEG054545.8 & 61.2 or 1.51.5
TYPEG067675.8 & 62.01.5
TYPEG076765.8 & 62.01.5
TYPEG1081085.8 & 62.51.5

Plastic Coating Characteristics

TestUnitLower Spec LimitUpper Spec Limit
Tensile StrengthN/mm [kg/cm2]29.52 10 [3.2]31.52 10 [3.0]
Elongation%70100
Compression strain% (25%)3.46
Water absorbing capacityG/m20.0030.008
Conductivity factorW/(mk2) [kcal/m2hm2]0.038(0.033)0.040(0.035)
Temperature of heat resistanceº C-40+114

The post Copper Pipe Plastic Coated Straight Length appeared first on Lawton Tubes.

]]>
Copper Pipe Straight Length https://lawtontubes.co.uk/product/copper-tube-plain-straight-length/ Tue, 27 Aug 2019 09:03:04 +0000 https://lawtontubes.co.uk/product/copper-tube-plain-straight-length/ Working Pressures / Mechanical Properties Dimensions and Tolerances (includes chrome plated and PVC covered) O.D.(mm) Wall (mm) Temper Max WorkingPressure bar up ThicknessTolerance  Diameter Tolerance Mean Diameter Tolerance Including Ovality 6 0.6 (TX) Half Hard 133 ±10% ± 0.04mm ±0.09mm 6 0.6 Soft 90 ±10% ± 0.04mm Not applicable 6 0.8 (TY) Half Hard 188 […]

The post Copper Pipe Straight Length appeared first on Lawton Tubes.

]]>
Working Pressures / Mechanical Properties

Dimensions and Tolerances (includes chrome plated and PVC covered)

O.D.
(mm)
Wall (mm)TemperMax Working
Pressure bar up
Thickness
Tolerance
 Diameter Tolerance MeanDiameter Tolerance Including Ovality
60.6 (TX)Half Hard133±10%± 0.04mm±0.09mm
60.6Soft90±10%± 0.04mmNot applicable
60.8 (TY)Half Hard188±10%± 0.04mm±0.09mm
80.6 (TX)Half Hard97±10%± 0.04mm±0.09mm
80.6Soft66±10%± 0.04mmNot applicable
80.8 (TY)Half Hard136±10%± 0.04mm±0.09mm
100.6 (TX)Half Hard77±10%± 0.04mm±0.09mm
100.7 (TY)Soft62±10%± 0.04mmNot applicable
100.8 (TY)Half Hard106±10%± 0.04mm±0.09mm
120.6 (TX)Half Hard63±10%± 0.04mm±0.09mm
120.8 (TY)Half Hard87±10%± 0.04mm±0.09mm
150.7 (TX)Half Hard58±10%± 0.04mm±0.09mm
151.0 (TY)Half Hard87±13%± 0.04mm±0.09mm
151.0 (TY)Soft67±13%± 0.04mmNot applicable
220.9 (TX)Half Hard51±10%± 0.05mm±0.10mm
221.2 (TY)Half Hard69±15%± 0.05mm±0.10mm
221.2 (TY)Soft57±15%± 0.05mmNot applicable
280.9 (TX)Half Hard40±10%± 0.05mm±0.10mm
281.2 (TY)Half Hard55±15%± 0.05mm±0.10mm
351.0 (LiteX)Hard42±15%± 0.06mm±0.07mm
351.2 (TX)Half Hard42±10%± 0.06mm±0.11mm
351.5 (TY)Hard64±10%± 0.06mm±0.07mm
421.0 (LiteX)Hard35±15%± 0.06mm±0.07mm
421.2 (TX)Half Hard35±10%± 0.06mm±0.11mm
421.5 (TY)Hard53±10%± 0.06mm±0.07mm
541.2 (TX)Hard33±15%± 0.06mm±0.07mm
542.0 (TY)Hard55±10%± 0.06mm±0.07mm
66.71.2 (TX)Hard26±15%± 0.07mm±0.10mm
66.72.0 (TY)Hard45±15%± 0.07mm±0.10mm
76.11.5 (TX)Hard29±15%± 0.07mm±0.10mm
76.12.0 (TY)Hard39±15%± 0.07mm±0.10mm
1081.5 (TX)Hard20±15%± 0.07mm±0.20mm
1082.5 (TY)Hard34±15%± 0.07mm±0.20mm
1331.5 (TX)Hard16±15%± 0.20mm±0.70mm
1592.0 (TX)Hard18±15%± 0.20mm±0.70mm
2193.0 (TX)Hard20±15%± 0.60mm±1.50mm

Water Capacity

Table W Microbore

O/D mmCapacity kg/m
60.0169
80.0347
100.0558

Table X 6mm – 159mm Copper Pipe capacity

O/D mmCapacity kg/m
60.0169
80.0347
100.0615
120.0890
150.1416
180.2063
220.3140
280.5308
350.8220
421.2163
542.0712
673.2134
764.1699
1088.6107
13313.2647
15918.8351

Table Y 6mm – 108mm

O/D mmCapacity kg/m
60.0139
80.0302
100.0529
120.0818
150.1280
180.1952
220.2943
280.5050
350.7888
421.1758
541.9317
673.2375
764.0438
1088.2527
Expansion of copper pipe lengths

Copper has a coefficient of linear expansion of 17 x 10-6C. For example, a 10m length of copper pipe carrying hot water at 60ºC will increase in length by almost 7mm when heated from 20ºC. Assuming the temperature cycling of the system is 20ºC, there will be a continuous cycle of expansion and contraction of 3.4mm. Refer to table below.

Temperature change3m4m5m6m7m8m9m10m12m25m
10°0.5mm0.7mm0.9mm1.0mm1.2mm1.4mm1.5mm1.7mm2.0mm4.3mm
20°1.0mm1.4mm1.7mm2.0mm2.4mm2.7mm3.0mm3.4mm4.0mm8.5mm
30°1.5mm2.0mm2.6mm3.1mm3.6mm4.1mm4.6mm5.1mm6.1mm13.0mm
40°2.0mm2.7mm3.4mm4.1mm4.8mm5.4mm6.1mm6.8mm8.2mm17.0mm
50°2.6mm3.4mm4.3mm5.1mm6.0mm6.8mm7.7mm8.5mm10.2mm21.0mm
60°3.1mm4.1mm5.1mm6.1mm7.1mm8.2mm9.2mm10.2mm12.2mm26.0mm
70°3.6mm4.8mm6.0mm7.1mm8.3mm9.5mm10.7mm11.9mm14.3mm30.0mm
80°4.1mm5.4mm6.8mm8.2mm9.5mm10.9mm12.2mm13.6mm16.3mm34.0mm
90°4.6mm6.1mm7.7mm9.2mm10.7mm12.2mm13.8mm15.3mm18.4mm38.0mm
100°5.1mm6.8mm8.5mm10.2mm11.9mm13.6mm15.3mm17.0mm20.4mm43.0mm
150°7.65mm10.2mm12.75mm15.3mm17.85mm20.4mm22.95mm25.5mm30.6mm63.75mm
200°10.2mm13.6mm17.0mm20.4mm23.8mm27.2mm30.6mm34.0mm40.8mm85.0mm
Supporting copper pipe length installations

Copper straight pipe installations have been tried and tested over many years of use in all parts of plumbing and heating systems. Copper’s versatility in such a wide variety of situations has resulted in the design and development of many different types of fixing clips and bracketing systems.

All pipework systems must be adequately supported if they are to give trouble-free service, especially over the long life of a copper system, some of which is illustrated in Figure 1.

Figure 1: Typical clips and brackets

Choosing the most appropriate clip or bracket depends on several factors that vary with the type of job and position or situation in which the straight length is installed.

For example, the pipe must be insulated against heat or frost in accordance with water regulations. In this situation, a simple plastic stand-off clip will not give sufficient clearance for the thickness of insulation required between the tube and the fixing surface. Therefore, an alternative type of support must be chosen, such as a ring bracket with a threaded rod and backplate.

Another factor which can affect an installation is the actual number of tube supports required. Because copper tube is a relatively rigid and self-supporting material, it requires comparatively fewer supports when compared to non-metallic tube.

How far apart should the supports for copper straight lengths be placed?

You will find the recommended intervals set out in Table 1 (below), which shows that fewer supports are required for vertical runs. This is because vertical straight lengths will not be subjected to possible sagging between supports. Excessive sagging can occur on horizontal runs of pipes made from any material if the supports are too far apart.

Another factor which must be considered, especially when considering supports for larger diameter tube and/or lightweight building structures is the method to be used to fix the tube support to the building fabric. The fixing method used should be able to transmit the weight of the tube and its contents to the building fabric, as well as any withstanding any other forces acting on the tube, without damage.

Diameter of Copper Pipe (mm)Intervals for Vertical Runs (m)Intervals for Horizontal Runs (m)
60.60.4
80.90.6
101.20.8
121.51
151.81.2
222.41.8
2.42.4
2832.4
3532.7
4233
5433
673.63
763.63
1083.63
1333.63
1594.23.6
Table 1: Recommended Maximum Fixing Intervals for Copper Tube Supports.
Bracing long runs of tube

For long copper straight pipe runs using hanging brackets, anchor bracing should be installed at 12m centers to prevent swaying of the straight pipe. In hot water lines, the allowable copper pipe length between anchor fixings and expansion joints depends on the joint’s type and movement capacity. Anchoring copper length at changes in direction (Figure 2) allows expansion to be managed by joints or expansion loops (installed horizontally to avoid airlocks).

For gland-type joints experiencing a 60°C temperature change and accommodating 25mm of expansion, the copper pipe length each side of the joint to an anchor can be up to 12.5m. This is because each meter of copper straight pipe changes in copper length by approximately 1mm per 60°C. Bellows-type joints should be installed with a “cold draw” to allow for expansion of the straight pipe.

Branch joints can serve as anchors, but “cross-over tees” (Figure 3) are needed if the connected copper pipe length will also move due to thermal expansion. Proper alignment of all straight pipe runs is crucial to prevent strain, especially when connecting copper pipe length to plastic cisterns, where backing plates or washers should be used to distribute load.

Figure 2
Figure 3

All tube runs should be aligned correctly to prevent undue strain. This is particularly important when connecting tube to a plastic cistern. Suitable backing plates or washers without sharp edges should be fitted between the tube connection and the cistern to spread any load.

Notching and drilling floor and roof joists

Notches and holes in simply supported floor and roof joists should be within the following limits:

  • Notches should be cut no deeper than 1/8 of the depth of the joist.
  • They should not be cut closer to the support than 0.07 times the span, nor further away than 1/4 of the span.

Drilled holes should be no greater in diameter than 1/4 of the depth of the joist. They should be drilled on the neutral axis and should be not less than 3 diameters apart, measured from centre to centre. Holes should be located in the area between 0.25 and 0.4 times the span of the joist from the support.

Note: Notches or holes for pipes must NOT be cut in roof rafters. Figure 4 shows the permitted limits of notches and holes in floor and roof joists.

Figure 4

Cabling soft copper tube through joists

The ability to drill holes through joists means that where soft coiled copper tube
(up to 10mm O.D. Table W or up to 12mm O.D. Table Y) is to be installed, it is quite easy to drill and cable the tube through the joists. This means that in new build work the tube can sometimes, if desired, be installed from below after the floorboards have been laid but before ceilings are boarded.

Use of Joist Clips

Where straight lengths of half–hard copper tube are required to be run in floors, they can be laid in notches. By using pipe joist clips with integral protective metal plates, the risk of damage due to punctures from nailing accidents should be eliminated. The rectangular shape of the joist clip can be used as a template when notching joists, which should avoid the joists being weakened accidentally by excessively deep notches.

Although unseen when the installation is complete, joist clips improve the overall quality of the installation. They do this by helping to align the straight length and permit expansion movement due to temperature changes in hot water lines. This will help to prevent clicking noises and the water hammer which can arise due to badly aligned pipework.

Frequently Asked Questions

What test certificates do you offer for your copper straight pipes and tubes?

All our copper pipes are manufactured to BS EN1057, ISO 9001, and are kitemarked.

What’s your minimum order for copper straight pipes?

Our minimum order for copper straight pipes is 1,000kgs of copper tube for FOC (approx. £6,000 ex VAT in value). For larger orders, please get in touch and we’ll be happy to help.

Where do your copper products originate from?

A large proportion of copper for our products, including our copper straight pipes and tubes, is mined in Chile. There are around 30 processing plants and factories around the world with a variety of capabilities, and, at Lawton Tubes, we have two drawing plants based in the UK.
