Lawtons lead free soft solder is a lead free alloy developed for plumbing and industrial applications of potable water supplies, heating and gas installations.

Type of Alloy

Compliant to the European and international standard: EN-ISO 9453: 2014.
Alloy No. 402
Alloy Designation S-Sn97Cu3
Melting Temperature 220 eutectic

Packing

Format: solid solder wire. Diameters: 0,35mm to 6mm. Delivered in reels of 500gr

Composition

97% Tin 3% Copper

Hazards Identification

Eyes: Burns caused by the melted material Skin: Burns caused by the melted material
Ingestion: Not applicable. Inhalation: Evacuate to fresh air and seek medical attention

First Aid Measures

Eyes Flush immediately with water. Get dermatologist attention. Skin Wash with soap and water Ingestion Wash mouth with water and seek medical attention. Inhalation Evacuate to fresh air and seek medical attention

Fire Fighting Measures

Specific hazards None, the product cannot explode or become inflamed.
Extinguishing media Not applicable
Fire-fighting equipment Not applicable

Accidental Released Measures

The supplied state of the material, present no risk of spillage.
Individual precautions – Use gloves to avoid burns in case of contact with the product.
Environmental protection precautions – Avoid the product entering into underground water pipes or ground waters.
Cleaning methods – Collect the product by mechanical means, avoiding dust formation. To remove completely, clean the surface with plenty of water.

Handling and Storage

Handling Whenever it is possible, avoid contact with skin. Use in well ventilated areas. Avoid direct inhalation of fumes. Preventive instructions against explosions and fires: no special requirements.

Storage – Requirements to be met by premises with storerooms and containers:

No special requirements.
Remarks for combined storage: not required
Further instructions about storage conditions:
Keep container tightly sealed.
Store in tightly closed and dry environments.
Storage class: VFD Class (Regulation on fluid fuels): deleted

Exposure Controls / Personal Protection

Additional instructions for the fitting of technical facilities: With the molten material: use in ventilated environments, or well equipped with fume extraction. Components with acceptable limit values that require monitoring at the workplace: the product does not contain any relevant quantities of substances which limit values must be controlled in the workplace.

Additional instructions: the current lists at the time of preparation were used as basis.

Personal protective equipment.

General protective and hygienic measures: Keep away from food, drinks and animal food. Wash hands before breaks and after work. Avoid contact with eyes and skin.
Respiratory protection: Use mask in poorly ventilated places.
Skin Protection: Gloves, only during the heating process.
Eye protection: Wear safety goggles to prevent potential spills during the operational phase.

Exposure limit values:
Substance Name VLA-ED (mg/m3) VLA-EC (mg/m3)

Tin	2	–
Copper	1	–

Physical and Chemical Properties

Appearance Solid
Colour Silver grey
Odour None
Flash point Not applicable
Combustion properties Non oxidant
Ignition Not applicable
Danger of explosion Not applicable
Relative density 7.33

Stability and Reactivity

Stability
Heat: heating may cause oxides steams and metal fumes.
Humidity: Keep the product dry.
Duration: Product not expired.

Toxicological Information

Acute toxicity Tin: 2 mg/ m3 Silver: 0,1 mg/ m3 Copper: 1 mg/ m3
Exposure ways Inhalation
Acute effects / symptoms During its heating may cause slight eye , nasal mucous and respiratory tract irritation.
Chronic effects Only after years of constant activity in unfavourable conditions, it may present risk of lung edema.

Ecological Information

General notes:
Level of damage to water 1 (self-classification): limited danger for water. Do not allow the undiluted product or in large quantities to infiltrate in ground waters, in water courses or in water pipes. It must not end up in sewers or drainage ditches.

Disposal Considerations

Storage and handling
Recommendation: Do not dispose of this substance with household waste. It should not reach sewer system.
Unclean packaging
Recommendation: Dispose of according to official regulations.

Information Concerning Transport

There is no special consideration in this regard.

Regulatory Information

Rating: This product is not subject to classification according to the criteria by the EC Directives on the Control of Dangerous Substances and Preparations.

R-Phrases: R 20/22 Harmful by inhalation and ingestion.
S-Phrases: S 2 Keep out of the reach of children.

S 13 Keep away from food, drinks and feed.
S 21 Do not smoke while using it.
S 26 In case of contact with eyes, rinse immediately with plenty water and consult a doctor.

WARNING: USE ONLY IN WELL VENTILATED AREAS
as when this product is heated may emit dangerous fumes for health if inhaled.

Lawtons leaded soft solder is a leaded alloy developed for plumbing and industrial applications of non-potable water supplies, heating and gas installations.

Type of Alloy

Compliant to the European and international standard: EN-ISO 9453: 2014.
Alloy No. 136
Alloy Designation Pb74Sn25Sb1
Melting Temperature 185 – 263oC

Packing

Format: solid solder wire. Diameters: 0,35mm to 6mm. Delivered in reels of 500gr

Composition

25% Tin 74% Lead 1% Antimony

Hazards Identification

Eyes: Burns caused by the melted material Skin: Burns caused by the melted material
Ingestion: Harmful due to lead content. Inhalation: It may be harmful and damage health in case of inhalation of the fumes emitted when this product is heated. It must be only used in ventilated areas.
The activators of the resin do not implied any hazard given its low concentration in the final product.

First Aid Measures

Eyes Flush immediately with water. Get dermatologist attention. Skin Wash with soap and water Ingestion Wash mouth with water and seek medical attention. Inhalation Evacuate to fresh air and seek medical attention

Fire Fighting Measures

Specific hazards None, the product cannot explode or become inflamed.
Extinguishing media Use pulverised water or foam
Fire-fighting equipment Foresee breathing protection. Use face mask

Accidental Released Measures

The supplied state of the material, present no risk of spillage.
Individual precautions – Use gloves to avoid burns in case of contact with the product.
Environmental protection precautions – Avoid the product entering into underground water pipes or ground waters.
Cleaning methods – Collect the product by mechanical means, avoiding dust formation. To remove completely, clean the surface with plenty of water.

Handling and Storage

Handling Whenever it is possible, avoid contact with skin. Use in well ventilated areas. Avoid direct inhalation of fumes. Preventive instructions against explosions and fires: no special requirements.

Storage – Requirements to be met by premises with storerooms and containers:

No special requirements.
Remarks for combined storage: not required
Further instructions about storage conditions:
Keep container tightly sealed.
Store in tightly closed and dry environments.
Storage class: VFD Class (Regulation on fluid fuels): deleted

Exposure Controls / Personal Protection

Additional instructions for the fitting of technical facilities: With the molten material: use in ventilated environments, or well equipped with fume extraction. Components with acceptable limit values that require monitoring at the workplace: the product does not contain any relevant quantities of substances which limit values must be controlled in the workplace.

Additional instructions: the current lists at the time of preparation were used as basis.

Personal protective equipment.
General protective and hygienic measures: Keep away from food, drinks and animal food. Wash hands before breaks and after work. Avoid contact with eyes and skin.
Respiratory protection: Use mask in poorly ventilated places.
Skin Protection: Gloves, only during the heating process.
Eye protection: Wear safety goggles to prevent potential spills during the operational phase.

Exposure limit values:
Substance Name VLA-ED (mg/m3) VLA-EC (mg/m3)

Tin	2	–
Lead	0.15	–

Physical and Chemical Properties

Appearance Solid
Colour Silver grey
Odour None
Flash point Not applicable
Combustion properties Non oxidant
Ignition Not applicable
Danger of explosion Not applicable
Relative density 10,54 Gr/cc.

Stability and Reactivity

Stability
Heat: heating may cause oxides steams and metal fumes.
Humidity: Keep the product dry.
Duration: Product not expired.

Toxicological Information

Acute toxicity Tin: 40 μg/m3 Lead: 2,0 mg/ m3
Exposure ways Inhalation
Acute effects / symptoms During its heating may cause slight eye , nasal mucous and respiratory tract irritation.
Chronic effects Only after years of constant activity in unfavourable conditions, it may present risk of lung edema.

Ecological Information

General notes:
Level of damage to water 1 (self-classification): limited danger for water. Do not allow the undiluted product or in large quantities to infiltrate in ground waters, in water courses or in water pipes. It must not end up in sewages or drainage ditches.

Disposal Considerations

Storage and handling
Recommendation: Do not dispose of this substance with household waste. It should not reach sewer system.
Unclean packaging
Recommendation: Dispose of according to official regulations.

Information Concerning Transport

There is no special consideration in this regard.

Regulatory Information

Rating: This product is not subject to classification according to the criteria by the EC Directives on the Control of Dangerous Substances and Preparations.

R-Phrases: R 20/22 Harmful by inhalation and ingestion.
S-Phrases: S 2 Keep out of the reach of children.

S 13 Keep away from food, drinks and feed.
S 21 Do not smoke while using it.
S 26 In case of contact with eyes, rinse immediately with plenty water and consult a doctor.

WARNING: USE ONLY IN WELL VENTILATED AREAS
as when this product is heated may emit dangerous fumes for health if inhaled.
